| Onderdeel nommer | LM238WF4-SSA1 |
| Handelsmerk | LG Display |
| Grootte | 23.8 |
| Toepassing | DMPC |
| Resolusie | 1920×1080 |
| Samestelling | LCM |
| Helderheid | 250 |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| paneel handelsmerk | LG Display |
| paneel model | LM238WF4-SSA1 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 23.8 inch |
| resolusie | 1920(RGB)×1080 , FHD |
| vertoonmodus | IPS, Normally Black, Transmissive |
| aktiewe area | 527.04×296.46 mm |
| buitelyn | 534.9×306.95×12.9 mm |
| oppervlak | Antiglare (Haze 25%), Hard coating (3H) |
| helderheid | 250 cd/m² (Typ.) |
| kontras verhouding | 1000:1 (Typ.) |
| kleure vertoon | 16.7M (6-bit + Hi-FRC), CIE193176% |
| reaksie tyd | 14 (Typ.)(G to G) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 14S4PWLEDWithout Driver |
| sein koppelvlak | LVDS (2 ch, 8-bit), 30 pins |
| insetspanning | 5.0V (Typ.) |
| aansoek | DMPC |
