| Onderdeel nommer | LM240WU4-SLB1 |
| Handelsmerk | LG Display |
| Grootte | 24.0 |
| Toepassing | DMPC |
| Resolusie | 1920×1200 |
| Samestelling | LCM |
| Helderheid | 400 |
| CR | 1000:1 |
| Kleure | 1.07B |
| Agterlig | CCFL |
| Koppelvlak | LVDS |
| paneel handelsmerk | LG Display |
| paneel model | LM240WU4-SLB1 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 24.0 inch |
| resolusie | 1920(RGB)×1200 , WUXGA |
| vertoonmodus | S-IPS, Normally Black, Transmissive |
| aktiewe area | 518.4×324 mm |
| buitelyn | 546.4×352×40.8 mm |
| oppervlak | Antiglare, Hard coating (3H) |
| helderheid | 400 cd/m² (Typ.) |
| kontras verhouding | 1000:1 (Typ.) |
| kleure vertoon | 1.07B (8-bit + Hi-FRC), CIE1931102% |
| reaksie tyd | 6/7 (Typ.)(Tr/Td); 6 (Typ.)(G to G) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 7 pcsCCFLEmbedded (Inverter) |
| sein koppelvlak | LVDS (2 ch, 10-bit), 51 pins |
| insetspanning | 12.0V (Typ.) |
| aansoek | DMPC |
