| Onderdeel nommer | MCT-G320240DTCW-151N |
| Handelsmerk | TRULY |
| Grootte | 5.7 |
| Toepassing | Industrial |
| Resolusie | 320×240 |
| Samestelling | CSTN-LCD , LCM |
| Helderheid | |
| CR | 45:1 |
| Kleure | Color |
| Agterlig | CCFL |
| Koppelvlak | Parallel |
| handelsmerk | TRULY |
| diagonale grootte | 5.7 inch |
| pixel formaat | 320(RGB)×240 [QVGA] 70PPI |
| aktiewe area | 115.18(H)×86.38(V) mm |
| ring area | 119.18(H)×90.38(V) mm |
| helderheid | 220 cd/m² (Typ.) |
| kyk rigting | - |
| kykhoek | 50/50/55/40 (Typ.)(CR≥10) |
| ondersteun kleur | Color |
| gewig | - |
| raamkoers | - |
| koppelvlak tipe | Parallel Data (1ch, 8-bit) , 16 pins Connector |
| omgewing | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -10 ~ 60 °C |
| model | MCT-G320240DTCW-151N |
| tipe | CSTN-LCD , LCM |
| konfigurasie | RGB Vertical Stripe |
| buitelyn dof. | 158.5(H)×109(V) ×9.2(D) mm |
| behandeling | - |
| kontras verhouding | 45:1 (Typ.) (TM) |
| reaksie tyd | 215/110 (Typ.)(Tr/Td) |
| bedryfsmodus | STN, Normally Black, Transmissive |
| Ligbron | CCFL [1 pcs] , 15K hours , W/O Driver |
| ontwerp vir | Industrial |
| raakpaneel | Without |
