| Onderdeel nommer | M238KCJ-L5B |
| Handelsmerk | Innolux |
| Grootte | 23.8 |
| Toepassing | Desktop Monitor |
| Resolusie | 2560×1440 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| handelsmerk | Innolux |
| diagonale grootte | 23.8 inch |
| pixel formaat | 2560(RGB)×1440 [Quad-HD] 123PPI |
| aktiewe area | 525.696(H)×295.704(V) mm |
| ring area | - |
| helderheid | 300 cd/m² (Typ.) |
| kyk rigting | Symmetry |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| ondersteun kleur | 16.7M 95% DCI-P3 |
| gewig | 2.40/2.52Kgs (Typ./Max.) |
| raamkoers | 60Hz |
| koppelvlak tipe | LVDS (4 ch, 8-bit) , 92 pins Connector |
| kragtoevoer | 10.0V (Typ.) |
| omgewing | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| model | M238KCJ-L5B |
| tipe | a-Si TFT-LCD , LCM |
| konfigurasie | RGB Vertical Stripe |
| buitelyn dof. | 536.3(H)×313.7(V) ×14.9(D) mm |
| behandeling | Antiglare (Haze 25%), Hard coating (3H) |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| reaksie tyd | 8/7 (Typ.)(Tr/Td) |
| bedryfsmodus | AAS, Normally Black, Transmissive |
| Ligbron | WLED , 30K hours , W/O Driver |
| ontwerp vir | Desktop Monitor |
| raakpaneel | Without |
