| Onderdeel nommer | M238HCA-LCZ |
| Handelsmerk | Innolux |
| Grootte | 23.8 |
| Toepassing | Desktop Monitor Gami |
| Resolusie | 1920×1080 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| handelsmerk | Innolux |
| diagonale grootte | 23.8 inch |
| pixel formaat | 1920(RGB)×1080 [FHD] 92PPI |
| aktiewe area | 527.04(H)×296.46(V) mm |
| ring area | - |
| helderheid | 250 cd/m² (Typ.) |
| kyk rigting | Symmetry |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| ondersteun kleur | 16.7M 99% sRGB |
| gewig | 2.23/2.34Kgs (Typ./Max.) |
| raamkoers | 60Hz |
| koppelvlak tipe | LVDS (2 ch, 8-bit) , 30 pins Connector |
| kragtoevoer | 5.0V (Typ.) |
| omgewing | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| model | M238HCA-LCZ |
| tipe | a-Si TFT-LCD , LCM |
| konfigurasie | RGB Vertical Stripe |
| buitelyn dof. | 535(H)×313(V) ×12.7(D) mm |
| behandeling | Antiglare (Haze 25%), Hard coating (3H) |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| reaksie tyd | 14 (Typ.)(G to G) |
| bedryfsmodus | AAS, Normally Black, Transmissive |
| Ligbron | WLED [4 strings] , 30K hours , W/O Driver |
| ontwerp vir | Desktop Monitor Gaming |
| raakpaneel | Without |
