| Onderdeel nommer | M238DTN01.6 CELL |
| Handelsmerk | AUO |
| Grootte | 23.8 |
| Toepassing | Desktop Monitor Gami |
| Resolusie | 2560×1440 |
| Samestelling | CELL , a-Si TFT-LC |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | No |
| Koppelvlak | eDP |
| vervaardiger | AUO |
| model naam | M238DTN01.6 CELL |
| skerm grootte | 23.8 inch |
| tipe skerm | CELL , a-Si TFT-LCD |
| pixel nommer | 2560(RGB)×1440 (Quad-HD) 123PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 526.85 × 296.35 (H×V) |
| buitelyn (mm) | - |
| helderheid | 0 cd/m² |
| kontras verhouding | 1000 : 1 (Typ.) (TM) |
| kykhoek | 85/85/80/80 (Typ.)(CR≥10) |
| reaksie | 3.5/1.5 (Typ.)(Tr/Td) ms |
| goeie uitsig by | - |
| werksmodus | TN, Normally White, Transmissive |
| kleurdiepte | 16.7M 72% NTSC |
| agterlig | No B/L |
| massa | - |
| gebruik vir | Desktop Monitor Gaming |
| herlaaitempo | - |
| raakskerm | Without |
| sein tipe | eDP Connector |
| maks. graderings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| G238HAN01.0 | AUO | 23.8 | 1920×1080 |
| LM238WF1-SLE1 | LG Display | 23.8 | 1920×1080 |
| LM238WF2-SSF1 | LG Display | 23.8 | 1920×1080 |
| LM238WF2-SSG2 | LG Display | 23.8 | 1920×1080 |
| LM238WF4-SSA1 | LG Display | 23.8 | 1920×1080 |
| LM238WR1-SLA1 | LG Display | 23.8 | 3840×2160 |
| M238DAN01.1 Q0 | AUO | 23.8 | 2560×1440 |
| M238HAN01.0 | AUO | 23.8 | 1920×1080 |
| MV238FHM-N10 | BOE | 23.8 | 1920×1080 |
| MV238QUM-N20 | BOE | 23.8 | 3840×2160 |
