| Onderdeel nommer | M101GWWF R0 |
| Handelsmerk | IVO |
| Grootte | 10.1 |
| Toepassing | Laptop |
| Resolusie | 1280×800 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 800:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| handelsmerk | IVO |
| model | M101GWWF R0 |
| diagonale grootte | 10.1 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 1280(RGB)×800 [WXGA] 149PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 216.96(H)×135.6(V) mm |
| buitelyn dof. | 229.46(H)×149.1(V) ×4.56(D) mm |
| ring area | - |
| behandeling | Glare (Haze 0%), Hard coating (3H) |
| helderheid | 350 cd/m² (Typ.) |
| kontras verhouding | 800:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 25 (Typ.)(Tr+Td) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| bedryfsmodus | IPS, Normally Black, Transmissive |
| ondersteun kleur | 16.7M |
| Ligbron | WLED , 25K hours , With LED Driver |
| vorm styl | Slim (PCBA Bent, T≤3.0mm) |
| ontwerp vir | Laptop |
| raamkoers | 60Hz |
| raakpaneel | Without |
| koppelvlak tipe | LVDS (1 ch, 8-bit) , 40 pins Connector |
| kragtoevoer | 3.3V (Typ.) |
| omgewing | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
