| Onderdeel nommer | M090AWA5 R0 |
| Handelsmerk | IVO |
| Grootte | 9.0 |
| Toepassing | Outdoor High Brightn |
| Resolusie | 1280×720 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | 7S4P |
| Koppelvlak | |
| vervaardiger | IVO |
| model naam | M090AWA5 R0 |
| skerm grootte | 9.0 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 1280(RGB)×720 (WXGA) 163PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 198.72 × 111.78 (H×V) |
| buitelyn (mm) | 212.2 × 127.5 × 10.5 (H×V×D) |
| ring area (mm) | 201.72 × 114.78 (H×V) |
| behandeling | Antiglare, Hard coating (3H), Reflection 6.0% (Max.) |
| helderheid | 880 cd/m² (Typ.) |
| kontras verhouding | 1000 : 1 (Typ.) (TM) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| reaksie | 30 (Typ.)(Tr+Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | IPS, Normally Black, Transmissive |
| kleurdiepte | 16.7M 70% NTSC |
| agterlig | 7S4P WLED , 15K hours , No Driver |
| massa | 335g (Max.) |
| gebruik vir | Outdoor High Brightness Automotive Display |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
