| Onderdeel nommer | M080AWP9 R0 |
| Handelsmerk | IVO |
| Grootte | 8.0 |
| Toepassing | Automotive Display |
| Resolusie | 800×480 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 700:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | Parallel |
| handelsmerk | IVO |
| model | M080AWP9 R0 |
| diagonale grootte | 8.0 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 800(RGB)×480 [WVGA] 115PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 175.2(H)×105.12(V) mm |
| buitelyn dof. | 186.5(H)×117.22(V) ×6.65(D) mm |
| ring area | 177.4(H)×107.32(V) mm |
| behandeling | Antiglare |
| helderheid | 750 cd/m² (Typ.) |
| kontras verhouding | 700:1 (Typ.) (TM) |
| kyk rigting | - |
| reaksie tyd | 13 (Typ.)(Tr+Td) |
| kykhoek | 70/70/50/70 (Typ.)(CR≥10) |
| bedryfsmodus | TN, Normally White, Transmissive |
| ondersteun kleur | 262K 70% NTSC |
| Ligbron | WLED [7S3P] , 30K hours , W/O Driver |
| gewig | 195/215g (Typ./Max.) |
| ontwerp vir | Automotive Display |
| raamkoers | 60Hz |
| raakpaneel | Without |
| koppelvlak tipe | Parallel RGB (1 ch, 6-bit) , 60 pins FPC |
| kragtoevoer | 3.3/10.6/22/-7.0V (Typ.)(VCC/VDDA/VGH/VGL) |
| omgewing | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C |
