| Onderdeel nommer | CLAA080WQ08 XN |
| Handelsmerk | CPT |
| Grootte | 8.0 |
| Toepassing | PAD |
| Resolusie | 800×1280 |
| Samestelling | LCM |
| Helderheid | 400 |
| CR | 900:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | MIPI |
| paneel handelsmerk | CPT |
| paneel model | CLAA080WQ08 XN |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 8.0 inch |
| resolusie | 800(RGB)×1280 , WXGA |
| vertoonmodus | HFFS, Normally Black, Transmissive |
| aktiewe area | 107.64×172.224 mm |
| buitelyn | 114.6×184.1×4 mm |
| oppervlak | Antiglare (Haze 25%), Hard coating (3H) |
| helderheid | 400 cd/m² (Typ.) |
| kontras verhouding | 900:1 (Typ.) |
| kleure vertoon | 16.7M (8-bit), CIE193153% |
| reaksie tyd | 25 (Typ.)(Tr+Td) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 7S3PWLEDWithout Driver |
| sein koppelvlak | MIPI (4 data lanes), 31 pins |
| insetspanning | 1.8/3.3V (Typ.)(VDDI/VCCI) |
| aansoek | PAD |
