| Onderdeel nommer | LQ235D1LW03 |
| Handelsmerk | SHARP |
| Grootte | 23.6 |
| Toepassing | IA |
| Resolusie | 1920×1080 |
| Samestelling | LCM |
| Helderheid | 400 |
| CR | 5000:1 |
| Kleure | 1.07B |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| paneel handelsmerk | SHARP |
| paneel model | LQ235D1LW03 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 23.6 inch |
| resolusie | 1920(RGB)×1080 , FHD |
| vertoonmodus | UV2A, Normally Black, Transmissive |
| aktiewe area | 521.28×293.22 mm |
| buitelyn | 554.8×319×21.4 mm |
| oppervlak | Antiglare (Haze 2%), Hard coating (3H) |
| helderheid | 400 cd/m² (Typ.) |
| kontras verhouding | 5000:1 (Typ.) |
| kleure vertoon | 1.07B (8-bit + Hi-FRC), CIE193172% |
| reaksie tyd | 4 (Typ.)(G to G) |
| kykhoek | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 120Hz |
| tipe lamp | 13S4PWLEDWithout Driver |
| sein koppelvlak | LVDS (4 ch, 10-bit), 92 pins |
| insetspanning | 12.0V (Typ.) |
| aansoek | IA |
