| Onderdeel nommer | LQ150X1DG11 |
| Handelsmerk | SHARP |
| Grootte | 15.0 |
| Toepassing | DMPC |
| Resolusie | 1024×768 |
| Samestelling | LCM |
| Helderheid | 200 |
| CR | 300:1 |
| Kleure | 262K |
| Agterlig | CCFL |
| Koppelvlak | TTL |
| paneel handelsmerk | SHARP |
| paneel model | LQ150X1DG11 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 15.0 inch |
| resolusie | 1024(RGB)×768 , XGA |
| vertoonmodus | TN, Normally White, Transmissive |
| aktiewe area | 304.128×228.096 mm |
| buitelyn | 331.3×257.9 mm |
| oppervlak | Antiglare (Haze 28%), Hard coating (2H) |
| helderheid | 200 cd/m² (Typ.) |
| kontras verhouding | 300:1 (Typ.) |
| kleure vertoon | 262K (6-bit) |
| reaksie tyd | 10/35 (Typ.)(Tr/Td) |
| kykhoek | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 2 pcsCCFLWithout Driver |
| sein koppelvlak | Parallel RGB (2 ch, 6-bit), 60 pins |
| insetspanning | 5.0V (Typ.)(VCC) |
| aansoek | DMPC |
