| Onderdeel nommer | LM238WR3-SSB1 |
| Handelsmerk | LG Display |
| Grootte | 23.8 |
| Toepassing | Desktop Monitor |
| Resolusie | 3840×2160 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1300:1 |
| Kleure | 1.07B |
| Agterlig | 18S3P |
| Koppelvlak | eDP |
| paneel handelsmerk | LG Display |
| paneel model | LM238WR3-SSB1 |
| paneel grootte | 23.8" |
| paneel tipe | a-Si TFT-LCD, LCM |
| resolusie | 3840(RGB)×2160, UHD, 185PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 525.658(W)×295.704(H) mm |
| ring opening | - |
| omtrek grootte | 536.3(W)×313.9(H) ×12.9(D) mm |
| oppervlak | Antiglare, Hard coating (3H) |
| helderheid | 350 cd/m² (Typ.) |
| kontras verhouding | 1300:1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| vertoonmodus | IPS, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 14 (Typ.)(G to G) |
| kleure vertoon | 1.07B 100% sRGB |
| tipe lamp | 18S3P WLED , 30K hours , Without Driver |
| frekwensie | 60Hz |
| raakskerm | Without |
| paneel gewig | 1.61/1.69Kgs (Typ./Max.) |
| aansoek | Desktop Monitor |
| sein koppelvlak | eDP (4 Lanes) , HBR2 (5.4G/lane) , 30 pins Connector |
| insetspanning | 10.0V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
