| Onderdeel nommer | LM230WF3-SLQ4 |
| Handelsmerk | LG Display |
| Grootte | 23.0 |
| Toepassing | Desktop Monitor |
| Resolusie | 1920×1080 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | 18S2P |
| Koppelvlak | LVDS |
| vervaardiger | LG Display |
| model naam | LM230WF3-SLQ4 |
| skerm grootte | 23.0 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 1920(RGB)×1080 (FHD) 95PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 509.184 × 286.416 (H×V) |
| buitelyn (mm) | 533.2 × 312 × 11 (H×V×D) |
| ring area (mm) | 513.8 × 291.0 (H×V) |
| behandeling | - |
| helderheid | - |
| kontras verhouding | 1000 : 1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| reaksie | 14 (Typ.)(G to G) ms |
| goeie uitsig by | Symmetry |
| werksmodus | IPS, Normally Black, Transmissive |
| kleurdiepte | 16.7M |
| agterlig | 18S2P WLED , 30K hours |
| massa | 1.93/2.03Kgs (Typ./Max.) |
| gebruik vir | Desktop Monitor |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| sein tipe | LVDS (2 ch, 8-bit) , Connector 30 pins |
| spanningstoevoer | 5.0V (Typ.) |
| maks. graderings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
