| Onderdeel nommer | LC470EUG-PEF2 |
| Handelsmerk | LG Display |
| Grootte | 47 |
| Toepassing | TV Sets |
| Resolusie | 1920×1080 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1400:1 |
| Kleure | 1.06B |
| Agterlig | WLED |
| Koppelvlak | EPI |
| paneel handelsmerk | LG Display |
| paneel model | LC470EUG-PEF2 |
| paneel grootte | 47" |
| paneel tipe | a-Si TFT-LCD, LCM |
| resolusie | 1920(RGB)×1080, FHD, 46PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 1039.68(W)×584.82(H) mm |
| ring opening | - |
| omtrek grootte | 1059.5(W)×616.2(H) mm |
| oppervlak | Antiglare (Haze 1%), Hard coating (2H) |
| helderheid | 360 cd/m² (Typ.) |
| kontras verhouding | 1400:1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Min.)(CR≥10) |
| vertoonmodus | S-IPS, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 8/10 (Typ.)(Tr/Td) |
| kleure vertoon | 1.06B 68% NTSC |
| tipe lamp | WLED , 50K hours , Without Driver |
| frekwensie | 120Hz |
| raakskerm | Without |
| paneel gewig | 10.5/11.0Kgs (Typ./Max.) |
| aansoek | TV Sets |
| sein koppelvlak | EPI , 100 pins Connector |
| insetspanning | 12.0V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
