| Onderdeel nommer | LC470DUE-SFR1 |
| Handelsmerk | LG Display |
| Grootte | 47 |
| Toepassing | LCTV |
| Resolusie | 1920×1080 |
| Samestelling | LCM |
| Helderheid | 300 |
| CR | 1200:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| paneel handelsmerk | LG Display |
| paneel model | LC470DUE-SFR1 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 47 inch |
| resolusie | 1920(RGB)×1080 , FHD |
| vertoonmodus | IPS, Normally Black, Transmissive |
| aktiewe area | 1039.68×584.82 mm |
| buitelyn | 1067.9×617.4 mm |
| oppervlak | Antiglare (Haze 1%), Hard coating (3H) |
| helderheid | 300 cd/m² (Typ.) |
| kontras verhouding | 1200:1 (Typ.) |
| kleure vertoon | 16.7M (8-bit), CIE193168% |
| reaksie tyd | 9 (Typ.)(G to G)(B/W) |
| kykhoek | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | WLEDWithout Driver |
| sein koppelvlak | LVDS (2 ch, 8-bit), 51 pins |
| insetspanning | 12.0V (Typ.) |
| aansoek | LCTV |
| LC470DUE-FGA3 | LG Display | 47 | 1920×1080 |
| LC470DUE-SFR1 | LG Display | 47 | 1920×1080 |
| LC470DUE-SFU2 | LG Display | 47 | 1920×1080 |
| LC470DUN-SFU2 | LG Display | 47 | 1920×1080 |
| LC470DUT-SEF2 | LG Display | 47 | 1920×1080 |
| LC470EUH-LFF1 | LG Display | 47 | 1920×1080 |
| LC470EUH-PFP1 | LG Display | 47 | 1920×1080 |
| LC470EUN-FEF1 | LG Display | 47 | 1920×1080 |
| LC470EUN-SDF1 | LG Display | 47 | 1920×1080 |
| LC470WUF-SCA3 | LG Display | 47 | 1920×1080 |
| LC370WUN-SCC1 | LG Display | 37 | 1920×1080 |
| LC420EUN-PFF1 | LG Display | 42 | 1920×1080 |
| LC550EQD-FGF4 | LG Display | 55 | 3840×2160 |
| LTA550HQ23-W | Samsung | 55 | 1920×1080 |
| LTZ400HM02 | Samsung | 40 | 1920×1080 |
| T315XW06 V0 | AUO | 31.5 | 1366×768 |
| T400HW01 V4 | AUO | 40 | 1920×1080 |
| T650QVR03.0 | AUO | 65 | 3840×2160 |
| V260B2-L04 | Innolux | 26.0 | 1366×768 |
| V460H1-LS1 | Innolux | 46 | 1920×1080 |
