| Onderdeel nommer | LA070WV7-SL02 |
| Handelsmerk | LG Display |
| Grootte | 7.0 |
| Toepassing | Outdoor High Brightn |
| Resolusie | 800×480 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 1100:1 |
| Kleure | 16.7M |
| Agterlig | 6S3P |
| Koppelvlak | LVDS |
| vervaardiger | LG Display |
| model naam | LA070WV7-SL02 |
| skerm grootte | 7.0 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 800(RGB)×480 (WVGA) 133PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 152.4 × 91.44 (H×V) |
| buitelyn (mm) | 166.4 × 106.2 × 10.7 (H×V×D) |
| ring area (mm) | 158.4 × 94.2 (H×V) |
| behandeling | Antiglare (Haze 25%) |
| helderheid | 1000 cd/m² (Typ.) |
| kontras verhouding | 1100 : 1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| reaksie | 16/14 (Typ.)(Tr/Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | IPS, Normally Black, Transmissive |
| kleurdiepte | 16.7M 65% NTSC |
| agterlig | 6S3P WLED , 30K hours , No Driver |
| massa | 162/167g (Typ./Max.) |
| gebruik vir | Outdoor High Brightness Automotive Display |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| sein tipe | LVDS (1 ch, 8-bit) , FPC 50 pins |
| spanningstoevoer | 3.3/13/18/-7.5V (Typ.)(DVDD/AVDD/VGH/VGL) |
| maks. graderings | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 5.0G (49.0 m/s²) |
