| Onderdeel nommer | LA070WV4-SD01 |
| Handelsmerk | LG Display |
| Grootte | 7.0 |
| Toepassing | CNS |
| Resolusie | 800×480 |
| Samestelling | LCM |
| Helderheid | 470 |
| CR | 900:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | TTL |
| paneel handelsmerk | LG Display |
| paneel model | LA070WV4-SD01 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 7.0 inch |
| resolusie | 800(RGB)×480 , WVGA |
| vertoonmodus | IPS, Normally Black, Transmissive |
| aktiewe area | 152.4×91.44 mm |
| buitelyn | 170×109.6 mm |
| oppervlak | Antiglare (Haze 11%) |
| helderheid | 470 cd/m² (Typ.) |
| kontras verhouding | 900:1 (Typ.) |
| kleure vertoon | 262K (6-bit), CIE193165% |
| reaksie tyd | 15/10 (Typ.)(Tr/Td) |
| kykhoek | 70/70/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 7S2PWLEDWithout Driver |
| sein koppelvlak | Parallel RGB (1 ch, 6-bit), 40 pins |
| insetspanning | 3.3V (Typ.) |
| aansoek | CNS |
