| Onderdeel nommer | KG057QV1EB-G000 |
| Handelsmerk | Kyocera |
| Grootte | 5.7 |
| Toepassing | Industrial |
| Resolusie | 320×240 |
| Samestelling | STN-LCD, LCM |
| Helderheid | |
| CR | 4:1 |
| Kleure | Monochrome |
| Agterlig | CCFL |
| Koppelvlak | |
| paneel handelsmerk | Kyocera |
| paneel model | KG057QV1EB-G000 |
| paneel grootte | 5.7" |
| paneel tipe | STN-LCD, LCM |
| resolusie | 320×240, QVGA, 70PPI |
| pixel formaat | Rectangle |
| vertoon area | 115.18(W)×86.38(H) mm |
| ring opening | - |
| helderheid | - |
| kontras verhouding | 4:1 (Typ.) (TM) |
| kykhoek | 45/45/20/40 (Typ.)(CR≥2) |
| vertoonmodus | STN, Blue mode (Negative), Transmissive |
| beste uitsig op | - |
| reaksie tyd | 380/120 (Typ.)(Tr/Td) |
| kleure vertoon | Monochrome |
| tipe lamp | CCFL |
| frekwensie | - |
| raakskerm | Without |
| paneel gewig | - |
| aansoek | Industrial |
| omgewing | Operating Temp.: 0 ~ 60 °C ; Storage Temp.: -20 ~ 60 °C |
| KG057QV1CA-G00 | Kyocera | 5.7 | 320×240 |
| KG057QV1CA-G000 | Kyocera | 5.7 | 320×240 |
| KG057QV1CA-G01 | Kyocera | 5.7 | 320×240 |
| KG057QV1CA-G02 | Kyocera | 5.7 | 320×240 |
| KG057QV1CA-G020 | Kyocera | 5.7 | 320×240 |
| KG057QV1CA-G020W | Kyocera | 5.7 | 320×240 |
| KG057QV1CA-G03 | Kyocera | 5.7 | 320×240 |
| KG057QV1CA-G04 | Kyocera | 5.7 | 320×240 |
| KG057QV1CF-G050 | Kyocera | 5.7 | 320×240 |
| KG057QV1DB-G00 | Kyocera | 5.7 | 320×240 |
