| Onderdeel nommer | KG057QV1EA-G020 |
| Handelsmerk | Kyocera |
| Grootte | 5.7 |
| Toepassing | Industrial |
| Resolusie | 320×240 |
| Samestelling | STN-LCD , LCM |
| Helderheid | |
| CR | 4:1 |
| Kleure | Monochrome |
| Agterlig | CCFL |
| Koppelvlak | |
| handelsmerk | Kyocera |
| diagonale grootte | 5.7 inch |
| pixel formaat | 320×240 [QVGA] 70PPI |
| aktiewe area | 115.18(H)×86.38(V) mm |
| helderheid | - |
| kyk rigting | - |
| kykhoek | 45/45/20/40 (Typ.)(CR≥2) |
| ondersteun kleur | Monochrome |
| gewig | - |
| raamkoers | - |
| omgewing | Operating Temperature: 0 ~ 60 °C ; Storage Temperature: -20 ~ 60 °C |
| model | KG057QV1EA-G020 |
| tipe | STN-LCD , LCM |
| konfigurasie | Rectangle |
| buitelyn dof. | - |
| kontras verhouding | 4:1 (Typ.) (TM) |
| reaksie tyd | 380/120 (Typ.)(Tr/Td) |
| bedryfsmodus | STN, Blue mode (Negative), Transmissive |
| Ligbron | CCFL |
| ontwerp vir | Industrial |
| raakpaneel | Without |
