| Onderdeel nommer | KCG057QV1DL-G770 |
| Handelsmerk | Kyocera |
| Grootte | 5.7 |
| Toepassing | Industrial |
| Resolusie | 320×240 |
| Samestelling | CSTN-LCD, LCM |
| Helderheid | |
| CR | 55:1 |
| Kleure | Color |
| Agterlig | CCFL |
| Koppelvlak | Parallel |
| handelsmerk | Kyocera |
| model | KCG057QV1DL-G770 |
| diagonale grootte | 5.7 inch |
| tipe | CSTN-LCD, LCM |
| pixel formaat | 320(RGB)×240 [QVGA] 70PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 115.2(H)×86.4(V) mm |
| buitelyn dof. | 144(H)×104.8(V) ×15.3(D) mm |
| ring area | 119.4(H)×90.6(V) mm |
| behandeling | Hard coating (2H) |
| helderheid | - |
| kontras verhouding | 55:1 (Typ.) (TM) |
| kyk rigting | - |
| reaksie tyd | 180/170 (Typ.)(Tr/Td) |
| kykhoek | 50/50/20/35 (Typ.)(CR≥2) |
| bedryfsmodus | STN, Normally Black, Transmissive |
| ondersteun kleur | Color |
| Ligbron | CCFL [1 pcs] |
| gewig | 220g (Typ.) |
| ontwerp vir | Industrial |
| raamkoers | 75Hz |
| raakpaneel | 4-wire Resistive Touch |
| koppelvlak tipe | Parallel Data (1ch, 8-bit) Connector |
| kragtoevoer | 3.3/5.0V (Typ.)(VDD) |
| omgewing | Operating Temperature: 0 ~ 60 °C ; Storage Temperature: -20 ~ 60 °C |
