| Onderdeel nommer | KCG057QV1DB-G760 |
| Handelsmerk | Kyocera |
| Grootte | 5.7 |
| Toepassing | IA |
| Resolusie | 320×240 |
| Samestelling | LCM |
| Helderheid | 380 |
| CR | 40:1 |
| Kleure | Color |
| Agterlig | CCFL |
| Koppelvlak | Parallel Data |
| paneel handelsmerk | Kyocera |
| paneel model | KCG057QV1DB-G760 |
| paneel tipe | CSTN-LCD , LCM |
| paneel grootte | 5.7 inch |
| resolusie | 320(RGB)×240 , QVGA |
| vertoonmodus | STN, Normally Black, Transmissive |
| aktiewe area | 115.2×86.4 mm |
| buitelyn | 144×104.8×13.2 mm |
| oppervlak | Glare (Haze 0%) |
| helderheid | 380 cd/m² (Typ.) |
| kontras verhouding | 40:1 (Typ.) |
| kleure vertoon | Color |
| reaksie tyd | 250/200 (Typ.)(Tr/Td) |
| kykhoek | 50/50/50/70 (Typ.)(CR≥2)(L/R/U/D) |
| frekwensie | 75Hz |
| tipe lamp | 1 pcsCCFLOptional |
| sein koppelvlak | Parallel Data (8-bit), 20 pins |
| insetspanning | 3.3/5.0V (Typ.)(VDD) |
| aansoek | IA |
