| Onderdeel nommer | HX121WX1-101 |
| Handelsmerk | HYDIS |
| Grootte | 12.1 |
| Toepassing | NBPC |
| Resolusie | 1280×800 |
| Samestelling | LCM |
| Helderheid | 300 |
| CR | 700:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| paneel handelsmerk | HYDIS |
| paneel model | HX121WX1-101 1 Compatible model |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 12.1 inch |
| resolusie | 1280(RGB)×800 , WXGA |
| vertoonmodus | AFFS, Normally Black, Transmissive |
| aktiewe area | 261.12×163.2 mm |
| buitelyn | 276.8×180×6.8 mm |
| oppervlak | Antiglare, Hard coating (2H) |
| helderheid | 300 cd/m² (Typ.) |
| kontras verhouding | 700:1 (Typ.) |
| kleure vertoon | 262K (6-bit), CIE193142% |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| kykhoek | 90/90/90/90 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 12S4PWLEDEmbedded (LED Driver) |
| sein koppelvlak | LVDS (1 ch, 6-bit), 40 pins |
| insetspanning | 3.3V (Typ.) |
| aansoek | NBPC |
| B121EW01 V0 | AUO | 12.1 | 1280×800 |
| HT12X21-220 | HYDIS | 12.1 | 1024×768 |
| HX121WX1-100 | HYDIS | 12.1 | 1280×800 |
| HX121WX1-101 | HYDIS | 12.1 | 1280×800 |
| HX121WX1-103 | HYDIS | 12.1 | 1280×800 |
| HX121WX1-110 | HYDIS | 12.1 | 1280×800 |
| HX121WX1-111 | HYDIS | 12.1 | 1280×800 |
| LP121X1-A2M1 | LG Display | 12.1 | 1024×768 |
| LT121DKXBF00 | TOSHIBA | 12.1 | 1280×800 |
| LTD121C31S | TOSHIBA | 12.1 | 800×600 |
| B140HAT02.0 | AUO | 14.0 | 1920×1080 |
| L141X1-1 | AUO | 14.1 | 1024×768 |
| LP140WH1-TLE3 | LG Display | 14.0 | 1366×768 |
| LP156WH2-TLAA | LG Display | 15.6 | 1366×768 |
| LP173WF1-TLA1 | LG Display | 17.3 | 1920×1080 |
| LTD121EDFN | TOSHIBA | 12.1 | 1024×768 |
| LTN121AP03-002 | Samsung | 12.1 | 1280×800 |
| LTN154X9-L02 | Samsung | 15.4 | 1280×800 |
| N133BGE-L31 | Innolux | 13.3 | 1366×768 |
| N156BGE-L31 | Innolux | 15.6 | 1366×768 |
