| Onderdeel nommer | HT12X21-220 |
| Handelsmerk | HYDIS |
| Grootte | 12.1 |
| Toepassing | PAD |
| Resolusie | 1024×768 |
| Samestelling | LCM |
| Helderheid | 180 |
| CR | 450:1 |
| Kleure | 262K |
| Agterlig | CCFL |
| Koppelvlak | LVDS |
| paneel handelsmerk | BOE HYDIS |
| paneel model | HT12X21-220 2 Compatible model |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 12.1 inch |
| resolusie | 1024(RGB)×768 , XGA |
| vertoonmodus | AFFS, Normally Black, Transmissive |
| aktiewe area | 245.76×184.32 mm |
| buitelyn | 270×199×7.2 mm |
| oppervlak | Antiglare (Haze 25%), Hard coating (3H) |
| helderheid | 180 cd/m² (Typ.) |
| kontras verhouding | 450:1 (Typ.) |
| kleure vertoon | 262K (6-bit), CIE193140% |
| reaksie tyd | 40 (Typ.)(Tr+Td) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 1 pcsCCFLWithout Driver |
| sein koppelvlak | LVDS (1 ch, 6-bit), 20 pins |
| insetspanning | 3.3V (Typ.) |
| aansoek | PAD |
