| Onderdeel nommer | HSD104KXN1-A10 |
| Handelsmerk | HannStar |
| Grootte | 10.4 |
| Toepassing | Automotive Display |
| Resolusie | 1024×768 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 900:1 |
| Kleure | 262K/16.2M |
| Agterlig | 4S8P |
| Koppelvlak | |
| vervaardiger | HannStar |
| model naam | HSD104KXN1-A10 |
| skerm grootte | 10.4 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 1024(RGB)×768 (XGA) 123PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 211.2 × 158.4 (H×V) |
| buitelyn (mm) | 236 × 174.3 × 7 (H×V×D) |
| ring area (mm) | 213.2 × 160.4 (H×V) |
| behandeling | Antiglare, Hard coating (3H) |
| helderheid | 600 cd/m² (Typ.) |
| kontras verhouding | 900 : 1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| reaksie | 30 (Typ.)(Tr+Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | IPS Pro, Normally Black, Transmissive |
| kleurdiepte | 262K/16.2M |
| agterlig | 4S8P WLED , 30K hours , No Driver |
| massa | 316g |
| gebruik vir | Automotive Display |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
