| Onderdeel nommer | H220VA01 |
| Handelsmerk | AUO |
| Grootte | 2.2 |
| Toepassing | Mobile Phone |
| Resolusie | 240×320 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 75:19:1 |
| Kleure | 262K |
| Agterlig | 4S1P |
| Koppelvlak | Parallel |
| vervaardiger | AUO |
| skerm grootte | 2.2 inch |
| pixel nommer | 240(RGB)×320 (QVGA) 180PPI |
| aktiewe area (mm) | 33.84 × 45.12 (H×V) |
| ring area (mm) | 35.4 × 46.92 (H×V) |
| helderheid | 100 cd/m² (Typ.) |
| kykhoek | 47/28/30/80 (Typ.)(CR≥10) |
| goeie uitsig by | 6 o'clock |
| kleurdiepte | 262K 42% NTSC |
| massa | - |
| herlaaitempo | - |
| sein tipe | Parallel RGB (1 ch, 6-bit) + SPI , 39 pins FPC |
| spanningstoevoer | 2.8V (Typ.) |
| maks. graderings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| model naam | H220VA01 |
| tipe skerm | LCM , a-Si TFT-LCD |
| reëling | RGB Vertical Stripe |
| buitelyn (mm) | 40.6 × 56.66 × 3.11 (H×V×D) |
| behandeling | - |
| kontras verhouding | 75 : 1 (Typ.) (TM) 9:1 (Typ.) (RF) |
| reaksie | 29 (Typ.)(Tr+Td) ms |
| werksmodus | TN, Normally White, Transflective |
| agterlig | 4S1P WLED , No Driver |
| gebruik vir | Mobile Phone |
| raakskerm | Without |
| AM-240320-022F | Other | 2.2 | 240×320 |
| DLC0220BMG | Other | 2.2 | 240×320 |
| DLC0220KZG | Other | 2.2 | 320×320 |
| HGS128321-B-EH-LV | Other | 2.2 | 128×32 |
| LMS220GF08 | Samsung | 2.2 | 240×320 |
| LS022Q8UD04 | SHARP | 2.2 | 240×320 |
| LTS220QC-F0J | Samsung | 2.2 | 176×220 |
| SG12232A | Other | 2.2 | 122×32 |
| TM022GDH11 | Tianma | 2.2 | 176×220 |
| TM022HDHT1-00 | Tianma | 2.2 | 240×320 |
