HGS128321-B-EH-LV

HGS128321-B-EH-LV
HGS128321-B-EH-LV
HGS128321-B-EH-LV
HGS128321-B-EH-LV thumb HGS128321-B-EH-LV thumb HGS128321-B-EH-LV thumb
Handelsmerk
Other
Grootte
2.2
Toepassing
IA
Resolusie
128×32
Samestelling
OLED
Helderheid
120
CR
2000:1
Kleure
Mono(Blue)
Agterlig
self
Koppelvlak
CPU/SPI/I²C
In Stock
13005
Spesifikasies

Onderdeel nommer HGS128321-B-EH-LV
HandelsmerkOther
Grootte2.2
ToepassingIA
Resolusie128×32
SamestellingOLED
Helderheid120
CR2000:1
KleureMono(Blue)
Agterligself
KoppelvlakCPU/SPI/I²C
paneel handelsmerkTSINGTEK
paneel modelHGS128321-B-EH-LV
paneel tipe PM-OLED , OLED
paneel grootte2.2 inch
resolusie128×32
aktiewe area55.02×13.1 mm
buitelyn66.5×35×10 mm
oppervlak
helderheid120 cd/m² (Typ.)
kontras verhouding2000 : 1 (Min.)
kleure vertoonMono(Blue)
kykhoek80/80/80/80 (Min.)(L/R/U/D)
bestuurder icBuilt-in SSD1305
sein koppelvlak8-bit 6800/8080 parallel, 4-wire SPI, I²C, 20 pins
insetspanning3.3V (Typ.)
aansoekIA
