| Onderdeel nommer | GV185FHM-N10-3M30 |
| Handelsmerk | BOE |
| Grootte | 18.5 |
| Toepassing | Industrial |
| Resolusie | 1920×1080 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1200:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| handelsmerk | BOE |
| model | GV185FHM-N10-3M30 |
| diagonale grootte | 18.5 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 1920(RGB)×1080 [FHD] 119PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 408.96(H)×230.04(V) mm |
| buitelyn dof. | 430.4(H)×254.6(V) ×12.5(D) mm |
| ring area | 410.96(H)×232.04(V) mm |
| behandeling | Antiglare (Haze 25%), Hard coating (3H) |
| helderheid | 350 cd/m² (Typ.) |
| kontras verhouding | 1200:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| bedryfsmodus | ADS, Normally Black, Transmissive |
| ondersteun kleur | 16.7M 70% NTSC |
| Ligbron | WLED [11S4P] , With LED Driver |
| gewig | 1.80Kgs (Typ.) |
| ontwerp vir | Industrial |
| raamkoers | 60Hz |
| raakpaneel | Without |
| koppelvlak tipe | LVDS (2 ch, 8-bit) , 30 pins Connector |
| kragtoevoer | 5.0V (Typ.) |
| omgewing | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
