| Onderdeel nommer | G156XW01 V4 |
| Handelsmerk | AUO |
| Grootte | 15.6 |
| Toepassing | Industrial |
| Resolusie | 1366×768 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 500:1 |
| Kleure | 16.2M |
| Agterlig | WLED |
| Koppelvlak | |
| paneel handelsmerk | AUO |
| paneel grootte | 15.6" |
| resolusie | 1366(RGB)×768, WXGA, 100PPI |
| vertoon area | 344.232(W)×193.536(H) mm |
| omtrek grootte | 363.8(W)×215.9(H) mm |
| helderheid | 500 cd/m² (Typ.) |
| kykhoek | 85/85/80/80 (Typ.)(CR≥10) |
| beste uitsig op | - |
| kleure vertoon | 16.2M 62% NTSC |
| frekwensie | 60Hz |
| gewig | 860±40g |
| paneel model | G156XW01 V4 |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | 347.54(W)×196.83(H) mm |
| oppervlak | Antiglare, Hard coating (3H) |
| kontras verhouding | 500:1 (Typ.) (TM) |
| vertoonmodus | TN, Normally White, Transmissive |
| reaksie tyd | 6/2 (Typ.)(Tr/Td) |
| tipe lamp | WLED , 50K hours , With LED Driver |
| raakskerm | Without |
| aansoek | Industrial |
