| Onderdeel nommer | G156HCE-L01 |
| Handelsmerk | Innolux |
| Grootte | 15.6 |
| Toepassing | Industrial |
| Resolusie | 1920×1080 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 800:1 |
| Kleure | 16.2M |
| Agterlig | WLED |
| Koppelvlak | |
| handelsmerk | Innolux |
| model | G156HCE-L01 |
| diagonale grootte | 15.6 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 1920(RGB)×1080 [FHD] 141PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 344.16(H)×193.59(V) mm |
| buitelyn dof. | 363.8(H)×215.98(V) ×9.6(D) mm |
| ring area | 347.06(H)×196.49(V) mm |
| behandeling | Antiglare, Hard coating (3H) |
| helderheid | 450 cd/m² (Typ.) |
| kontras verhouding | 800:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 13/12 (Typ.)(Tr/Td) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| bedryfsmodus | AAS, Normally Black, Transmissive |
| ondersteun kleur | 16.2M 73% NTSC |
| Ligbron | WLED , 50K hours , With LED Driver |
| gewig | 1.06/1.10Kgs (Typ./Max.) |
| ontwerp vir | Industrial |
| raamkoers | 60Hz |
| raakpaneel | Without |
| Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C |
