| Onderdeel nommer | G121XGE-L01 |
| Handelsmerk | Innolux |
| Grootte | 12.1 |
| Toepassing | Industrial Automotiv |
| Resolusie | 768×1024 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 700:1 |
| Kleure | 262K/16.2M |
| Agterlig | WLED |
| Koppelvlak | |
| paneel handelsmerk | Innolux |
| paneel grootte | 12.1" |
| resolusie | 768(RGB)×1024, XGA, 105PPI |
| vertoon area | 184.32(W)×245.76(H) mm |
| omtrek grootte | 204(W)×260.5(H) ×8.9(D) mm |
| helderheid | 600 cd/m² (Typ.) |
| kykhoek | 70/70/80/80 (Typ.)(CR≥10) |
| beste uitsig op | - |
| kleure vertoon | 262K/16.2M 63% NTSC |
| frekwensie | 60Hz |
| gewig | 510/540g (Typ./Max.) |
| paneel model | G121XGE-L01 |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | 187.5(W)×249.0(H) mm |
| oppervlak | Glare (Haze 0%), Hard coating (3H) |
| kontras verhouding | 700:1 (Typ.) (TM) |
| vertoonmodus | TN, Normally White, Transmissive |
| reaksie tyd | 5/11 (Typ.)(Tr/Td) |
| tipe lamp | WLED , 50K hours , With LED Driver |
| raakskerm | Without |
| aansoek | Industrial Automotive Display |
| AA121SL09 | Mitsubishi | 12.1 | 800×600 |
| AA121TH11-DE1 | Mitsubishi | 12.1 | 1280×800 |
| G121X1-L01 | Innolux | 12.1 | 1024×768 |
| G121X1-L03 | Innolux | 12.1 | 1024×768 |
| G121X1-L04 | Innolux | 12.1 | 1024×768 |
| G121XN01 V0 | AUO | 12.1 | 1024×768 |
| G121XTN01.0 | AUO | 12.1 | 1024×768 |
| LP121WX3-TLA1 | LG Display | 12.1 | 1280×800 |
| LTD121EX1S | TOSHIBA | 12.1 | 1280×768 |
| NL8060BC31-27 | NLT | 12.1 | 800×600 |
