| Onderdeel nommer | G101EVT03.2 |
| Handelsmerk | AUO |
| Grootte | 10.1 |
| Toepassing | Industrial |
| Resolusie | 1280×800 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1300:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | |
| vervaardiger | AUO |
| model naam | G101EVT03.2 |
| skerm grootte | 10.1 inch |
| tipe skerm | LCM , a-Si TFT-LCD |
| pixel nommer | 1280(RGB)×800 (WXGA) 149PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 216.96 × 135.6 (H×V) |
| buitelyn (mm) | - |
| helderheid | - |
| kontras verhouding | 1300 : 1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| reaksie | 25 (Typ.)(Tr+Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | MVA, Normally Black, Transmissive |
| kleurdiepte | 262K 45% NTSC |
| agterlig | WLED |
| massa | - |
| gebruik vir | Industrial |
| herlaaitempo | 60Hz |
| raakskerm | - |
| AM-1280800N1TZQW-T06H | AMPIRE | 10.1 | 1280×800 |
| AM-1280800N2TZQW-T48H | AMPIRE | 10.1 | 1280×800 |
| B101EAN02.2 | AUO | 10.1 | 800×1280 |
| CLAA101WA01A | CPT | 10.1 | 1366×768 |
| G101EVN01.0 | AUO | 10.1 | 1280×800 |
| G101EVN01.3 | AUO | 10.1 | 1280×800 |
| HSD100IFW3-A00 | HannStar | 10.1 | 1024×600 |
| HV101HD1-1E0 | HYDIS | 10.1 | 1366×768 |
| N101L6-L01 | Innolux | 10.1 | 1024×600 |
| VVX10F004B00 | Panasonic | 10.1 | 1920×1200 |
