| Onderdeel nommer | HV101HD1-1E0 |
| Handelsmerk | HYDIS |
| Grootte | 10.1 |
| Toepassing | PAD |
| Resolusie | 1366×768 |
| Samestelling | LCM |
| Helderheid | |
| CR | 800:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| paneel handelsmerk | HYDIS |
| paneel model | HV101HD1-1E0 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 10.1 inch |
| resolusie | 1366(RGB)×768 , WXGA |
| vertoonmodus | HFFS, Normally Black, Transmissive |
| aktiewe area | 223.341×125.568 mm |
| oppervlak | |
| helderheid | |
| kontras verhouding | 800:1 (Typ.) |
| kleure vertoon | 16.7M (8-bit), CIE193150% |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | WLEDEmbedded (LED Driver) |
| sein koppelvlak | LVDS (1 ch, 8-bit), 40 pins |
| insetspanning | 3.3V (Typ.) |
| aansoek | PAD |
