| Onderdeel nommer | G101EAN02.2 |
| Handelsmerk | AUO |
| Grootte | 10.1 |
| Toepassing | Industrial |
| Resolusie | 1280×800 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 800:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| paneel handelsmerk | AUO |
| paneel model | G101EAN02.2 |
| paneel grootte | 10.1" |
| paneel tipe | a-Si TFT-LCD, LCM |
| resolusie | 1280(RGB)×800, WXGA, 149PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 216.96(W)×135.6(H) mm |
| ring opening | - |
| omtrek grootte | 227.91(W)×148(H) ×7.75(D) mm |
| oppervlak | Hard coating |
| helderheid | 500 cd/m² (Typ.) |
| kontras verhouding | 800:1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| vertoonmodus | AHVA, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 29 (Typ.)(Tr+Td) |
| kleure vertoon | 16.7M 50% NTSC |
| tipe lamp | WLED , 50K hours , With LED Driver |
| frekwensie | 60Hz |
| raakskerm | Without |
| paneel gewig | 290g (Max.) |
| aansoek | Industrial |
| sein koppelvlak | LVDS (1 ch, 8-bit) , 40 pins Connector |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -20 ~ 70 °C |
| B101UAT02.1 | AUO | 10.1 | 1920×1200 |
| BA101WS1-100 | BOE | 10.1 | 1024×600 |
| EJ101IA-01C | Innolux | 10.1 | 1280×800 |
| G101EVN01.0 | AUO | 10.1 | 1280×800 |
| G101EVN01.3 | AUO | 10.1 | 1280×800 |
| HSD100IFW4-A00 | HannStar | 10.1 | 1024×600 |
| HSD101PFW4-A00 | HannStar | 10.1 | 1024×600 |
| LP101WSA-TLB1 | LG Display | 10.1 | 1024×600 |
| LP101WX2-SLP1 | LG Display | 10.1 | 1280×800 |
| M101NWT2 R2 | IVO | 10.1 | 1024×600 |
