| Onderdeel nommer | G080UAN01.0 |
| Handelsmerk | AUO |
| Grootte | 8.0 |
| Toepassing | Industrial |
| Resolusie | 1200×1920 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | 8S3P |
| Koppelvlak | |
| paneel handelsmerk | AUO |
| paneel grootte | 8.0" |
| resolusie | 1200(RGB)×1920, WUXGA, 283PPI |
| vertoon area | 107.64(W)×172.224(H) mm |
| omtrek grootte | 114.6(W)×184.13(H) ×3.95(D) mm |
| helderheid | 500 cd/m² (Typ.) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| kleure vertoon | 16.7M 60% NTSC |
| frekwensie | 60Hz |
| gewig | 80g (Max.) |
| paneel model | G080UAN01.0 |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | - |
| oppervlak | Glare (Haze 0%) |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| vertoonmodus | AHVA, Normally Black, Transmissive |
| reaksie tyd | 27 (Typ.)(Tr+Tf) |
| tipe lamp | 8S3P WLED , 20K hours , Without Driver |
| raakskerm | Without |
| aansoek | Industrial |
| B080EAN02.0 | AUO | 8.0 | 800×1280 |
| BP080WX1-100 | BOE | 8.0 | 1280×800 |
| CLAA080NA01 CW | CPT | 8.0 | 1024×600 |
| HJ080IA-01F | Innolux | 8.0 | 1024×768 |
| LA080WV1-TD01 | LG Display | 8.0 | 800×480 |
| LA080WV3-SD01 | LG Display | 8.0 | 800×480 |
| LQ080T5GG01B | SHARP | 8.0 | 480×234 |
| LQ080Y5DW30 | SHARP | 8.0 | 800×480 |
| PD080SL1 | E Ink | 8.0 | 800×600 |
| PD080SL2 | E Ink | 8.0 | 800×600 |
