| Onderdeel nommer | F080A35-602 |
| Handelsmerk | Innolux |
| Grootte | 8.0 |
| Toepassing | Digital Photo Frame |
| Resolusie | 1024×768 |
| Samestelling | a-Si TFT-LCD , CELL |
| Helderheid | |
| CR | 800:1 |
| Kleure | 16.7M |
| Agterlig | No |
| Koppelvlak | |
| paneel handelsmerk | Innolux |
| paneel grootte | 8.0" |
| resolusie | 1024(RGB)×768, XGA, 160PPI |
| vertoon area | 162.048(W)×121.536(H) mm |
| omtrek grootte | 171.124(W)×132.618(H) ×0.8(D) mm |
| helderheid | 0 cd/m² |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| glas diepte | 0.40+0.40 mm |
| kleure vertoon | 16.7M |
| frekwensie | - |
| bestuurder ic | COG Suggest NT39212C+NT51008 |
| paneel gewig | - |
| omgewing | Operating Temp.: -10 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| paneel model | F080A35-602 |
| paneel tipe | a-Si TFT-LCD , CELL |
| pixel formaat | RGB Vertical Stripe |
| ring opening | - |
| oppervlak | - |
| kontras verhouding | 800:1 (Typ.) (TM) |
| vertoonmodus | AAS, Normally Black, Transmissive |
| reaksie tyd | 25 (Typ.)(Tr+Td) |
| deurlaatbaarheid | 4.0% (Typ.) |
| tipe lamp | No B/L |
| raakskerm | Without |
| aansoek | Digital Photo Frame |
| A080SN03 V0 | AUO | 8.0 | 800×600 |
| AT080TN43 | Innolux | 8.0 | 800×600 |
| B080EAN02.0 | AUO | 8.0 | 800×1280 |
| CLAA080LJ01CW | CPT | 8.0 | 800×480 |
| CLAA080MB0DCW | CPT | 8.0 | 800×600 |
| CLAA080WQ02 XG | CPT | 8.0 | 800×1280 |
| EK08009-70235 | Other | 8.0 | 800×600 |
| HJ080IA-01F | Innolux | 8.0 | 1024×768 |
| HSD080IFW1-A00 | HannStar | 8.0 | 1024×600 |
| ZJ080NA-08A | Innolux | 8.0 | 1024×600 |
