| Onderdeel nommer | EV101WUM-N20 |
| Handelsmerk | BOE |
| Grootte | 10.1 |
| Toepassing | Medical Imaging |
| Resolusie | 1920×1200 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 900:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| handelsmerk | BOE |
| model | EV101WUM-N20 |
| diagonale grootte | 10.1 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 1920(RGB)×1200 [WUXGA] 224PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 216.806(H)×135.504(V) mm |
| buitelyn dof. | 229.45(H)×149.22(V) mm |
| helderheid | 600 cd/m² (Typ.) |
| kontras verhouding | 900:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| bedryfsmodus | ADS, Normally Black, Transmissive |
| ondersteun kleur | 16.7M 72% NTSC |
| Ligbron | WLED , W/O Driver |
| gewig | - |
| ontwerp vir | Medical Imaging |
| raamkoers | 60Hz |
| raakpaneel | Without |
| koppelvlak tipe | LVDS (1 ch, 8-bit) , 45 pins Connector |
| kragtoevoer | 3.3V (Typ.) |
| omgewing | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -25 ~ 80 °C |
