| Onderdeel nommer | ET024012DMA |
| Handelsmerk | EDT |
| Grootte | 2.4 |
| Toepassing | Handheld & PDA |
| Resolusie | 240×320 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 820:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | 8/9/16/18-bit |
| handelsmerk | EDT |
| model | ET024012DMA |
| diagonale grootte | 2.4 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 240(RGB)×320 [QVGA] 166PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 36.72(H)×48.96(V) mm |
| buitelyn dof. | 42.72(H)×60.4(V) mm |
| ring area | 37.72(H)×49.96(V) mm |
| behandeling | - |
| helderheid | 350 cd/m² (Typ.) |
| kontras verhouding | 820:1 (Typ.) (TM) |
| kyk rigting | - |
| reaksie tyd | 35 (Typ.)(Tr+Td) |
| kykhoek | 70/70/70/70 (Typ.)(CR≥10) |
| bedryfsmodus | TN, Normally White, Transmissive |
| ondersteun kleur | 262K 59% NTSC |
| Ligbron | WLED [4S1P] , 10K hours , W/O Driver |
| gewig | - |
| ontwerp vir | Handheld & PDA |
| raamkoers | 60Hz |
| raakpaneel | Without |
| koppelvlak tipe | 8/9/16/18-bit 8080 parallel , 35 pins FPC |
| kragtoevoer | 3.0/3.0V (Typ.)(VCI/IOVCC) |
| omgewing | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
