| Onderdeel nommer | DMF-50840NF-FW |
| Handelsmerk | OPTREX |
| Grootte | 5.7 |
| Toepassing | Industrial |
| Resolusie | 320×240 |
| Samestelling | FSTN-LCD , LCM |
| Helderheid | |
| CR | 15:1 |
| Kleure | Monochrome |
| Agterlig | 1 |
| Koppelvlak | |
| paneel handelsmerk | OPTREX |
| paneel grootte | 5.7" |
| resolusie | 320×240, QVGA, 70PPI |
| vertoon area | 115.2(W)×86.4(H) mm |
| omtrek grootte | 167.1(W)×109(H) ×11(D) mm |
| helderheid | 50 cd/m² (Typ.) |
| kykhoek | 40/50/30/40 (Typ.)(CR≥2) |
| beste uitsig op | 6 o'clock |
| kleure vertoon | Monochrome |
| frekwensie | 75Hz |
| gewig | 230g (Max.) |
| paneel model | DMF-50840NF-FW |
| paneel tipe | FSTN-LCD , LCM |
| pixel formaat | Rectangle |
| ring opening | 120.0(W)×90.0(H) mm |
| oppervlak | - |
| kontras verhouding | 15:1 (Typ.) (TM) |
| vertoonmodus | STN, Black/White (Negative), Transmissive |
| reaksie tyd | 420/210 (Typ.)(Tr/Td) |
| tipe lamp | 1 pcs CCFL , 25K hours , Without Driver |
| raakskerm | Without |
| aansoek | Industrial |
| CLAA057VA01CW | CPT | 5.7 | 640×480 |
| DMF-50840NB-FW | Kyocera | 5.7 | 320×240 |
| EL320.240.36 ET | Lumineq | 5.7 | 320×240 |
| EL320.240.36 HB | Lumineq | 5.7 | 320×240 |
| KG057QV1CA-G020 | Kyocera | 5.7 | 320×240 |
| LM057QB1T09 | SHARP | 5.7 | 320×240 |
| LM24P20 | SHARP | 5.7 | 240×128 |
| LQ6NC02 | SHARP | 5.7 | 240×240 |
| TCG057QVLCA-G00 | Kyocera | 5.7 | 320×240 |
| UMSH-8377MD-8T | Other | 5.7 | 640×480 |
