| Onderdeel nommer | COM55T5103RSP |
| Handelsmerk | CASIO |
| Grootte | 5.5 |
| Toepassing | Industrial |
| Resolusie | 320×234 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 60:1 |
| Kleure | Full |
| Agterlig | 1 |
| Koppelvlak | Analog |
| paneel handelsmerk | CASIO |
| paneel grootte | 5.5" |
| resolusie | 320(RGB)×234, 72PPI |
| vertoon area | 110.4(W)×83.538(H) mm |
| omtrek grootte | 163(W)×115(H) ×32.5(D) mm |
| helderheid | 350 cd/m² (Typ.) |
| kykhoek | 35/35/30/35 (Typ.)(CR≥10) |
| beste uitsig op | 12 o'clock |
| kleure vertoon | Full color |
| frekwensie | 60Hz |
| paneel gewig | 400g (Typ.) |
| sein koppelvlak | Analog RGB , 12 pins Connector |
| insetspanning | 12.0V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -10 ~ 60 °C |
| paneel model | COM55T5103RSP |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | - |
| oppervlak | - |
| kontras verhouding | 60:1 (Min.) (TM) |
| vertoonmodus | TN, Normally White, Transmissive |
| reaksie tyd | - |
| tipe lamp | 1 pcs CCFL , With Inverter |
| raakskerm | Without |
| aansoek | Industrial |
| BT055FWM-N00 | BOE | 5.5 | 480×854 |
| CM546B1-002 | CSOT | 5.5 | 1080×1920 |
| LH550WF2-SD01 | LG Display | 5.5 | 1080×1920 |
| LM32C041 | SHARP | 5.5 | 320×240 |
| LM6Q35 | SHARP | 5.5 | 320×240 |
| LQ055T3SX04 | SHARP | 5.5 | 1080×1920 |
| LS055R1SC01 | SHARP | 5.5 | 1440×2560 |
| NL3224AC35-01 | NLT | 5.5 | 320×240 |
| NL3224BC35-20R | NLT | 5.5 | 320×240 |
| TM055XDHP10 | Tianma | 5.5 | 540×960 |
