| Onderdeel nommer | BT055FWM-N00 |
| Handelsmerk | BOE |
| Grootte | 5.5 |
| Toepassing | MPH |
| Resolusie | 480×854 |
| Samestelling | LCM |
| Helderheid | 300 |
| CR | 700:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | MIPI |
| paneel handelsmerk | BOE |
| paneel model | BT055FWM-N00 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 5.5 inch |
| resolusie | 480(RGB)×854 , FWVGA |
| vertoonmodus | TN, Normally White, Transmissive |
| aktiewe area | 68.04×121.05 mm |
| buitelyn | 72.34×130.86×2.3 mm |
| oppervlak | Antiglare |
| helderheid | 300 cd/m² (Typ.) |
| kontras verhouding | 700:1 (Typ.) |
| kleure vertoon | 16.7M (8-bit) |
| reaksie tyd | 25 (Typ.)(Tr+Td) |
| kykhoek | 70/70/70/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 5S2PWLEDWithout Driver |
| sein koppelvlak | MIPI (2 data lanes), 25 pins |
| insetspanning | 1.8/2.8V (Typ.)(IOVCC/VCC) |
| aansoek | MPH |
