| Onderdeel nommer | CLAA190EB02 CW |
| Handelsmerk | CPT |
| Grootte | 19.0 |
| Toepassing | Desktop Monitor Indu |
| Resolusie | 1280×1024 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | |
| handelsmerk | CPT |
| model | CLAA190EB02 CW |
| diagonale grootte | 19.0 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 1280(RGB)×1024 [SXGA] 86PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 376.32(H)×301.056(V) mm |
| buitelyn dof. | 396(H)×324(V) ×15.38(D) mm |
| ring area | 379.72(H)×304.456(V) mm |
| behandeling | - |
| helderheid | - |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| kyk rigting | - |
| reaksie tyd | 16 (Typ.)(Tr+Td) |
| kykhoek | 85/85/80/80 (Typ.)(CR≥10) |
| bedryfsmodus | TN, Normally White, Transmissive |
| ondersteun kleur | 16.7M 72% NTSC |
| Ligbron | WLED |
| gewig | - |
| ontwerp vir | Desktop Monitor Industrial |
| raamkoers | 60Hz |
| raakpaneel | Without |
| Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
