M190EN03 V0

M190EN03 V0
M190EN03 V0
M190EN03 V0 thumb M190EN03 V0 thumb
Handelsmerk
AUO
Grootte
19.0
Toepassing
DMPC
Resolusie
1280×1024
Samestelling
LCM
Helderheid
250
CR
1000:1
Kleure
16.7M
Agterlig
CCFL
Koppelvlak
LVDS
In Stock
18771
Spesifikasies

Onderdeel nommer M190EN03 V0
HandelsmerkAUO
Grootte19.0
ToepassingDMPC
Resolusie1280×1024
SamestellingLCM
Helderheid250
CR1000:1
Kleure16.7M
AgterligCCFL
KoppelvlakLVDS
paneel handelsmerkAUO
paneel modelM190EN03 V0
paneel tipe a-Si TFT-LCD , LCM
paneel grootte19.0 inch
resolusie1280(RGB)×1024 , SXGA
vertoonmodusMVA, Normally Black, Transmissive
aktiewe area376.32×301.056 mm
buitelyn396×324×18 mm
oppervlakAntiglare, Hard coating (3H)
helderheid250 cd/m² (Typ.)
kontras verhouding1000:1 (Typ.)
kleure vertoon16.7M (6-bit + Hi-FRC)
reaksie tyd20 (Typ.)(Tr+Td); 8 (Typ.)(G to G)
kykhoek85/85/85/85 (Typ.)(CR＞10)(L/R/U/D)
frekwensie60Hz
tipe lamp4 pcsCCFLWithout Driver
sein koppelvlakLVDS (2 ch, 8-bit), 30 pins
insetspanning5.0V (Typ.)
aansoekDMPC
Familie Model
M190E5-L0G Innolux 19.0 1280×1024
M190EG01 V2 AUO 19.0 1280×1024
M190EG02 V4 AUO 19.0 1280×1024
M190EG02 V7 AUO 19.0 1280×1024
M190EG02 V9 AUO 19.0 1280×1024
M190EN01 V1 AUO 19.0 1280×1024
M190EN03 V0 AUO 19.0 1280×1024
M190EN03 V2 AUO 19.0 1280×1024
M190EN04 V5 AUO 19.0 1280×1024
M190ETN01.0 AUO 19.0 1280×1024
