| Onderdeel nommer | CLAA141WB11 |
| Handelsmerk | CPT |
| Grootte | 14.1 |
| Toepassing | NBPC |
| Resolusie | 1280×800 |
| Samestelling | LCM |
| Helderheid | 220 |
| CR | 300:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| paneel handelsmerk | CPT |
| paneel model | CLAA141WB11 2 Compatible model |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 14.1 inch |
| resolusie | 1280(RGB)×800 , WXGA |
| vertoonmodus | TN, Normally White, Transmissive |
| aktiewe area | 303.74×189.84 mm |
| buitelyn | 319.5×205.5×5.5 mm |
| vorm styl | Wedge (PCBA Bent, Depth ≥5.2mm) |
| oppervlak | Antiglare, Hard coating (3H) |
| helderheid | 220 cd/m² (Typ.) |
| kontras verhouding | 300:1 (Min.) |
| kleure vertoon | 262K (6-bit), CIE193145% |
| reaksie tyd | 4/8 (Typ.)(Tr/Td) |
| kykhoek | 40/40/15/30 (Min.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 8S6PWLEDWithout Driver |
| sein koppelvlak | LVDS (1 ch, 6-bit), 30 pins |
| insetspanning | 3.3V (Typ.) |
| aansoek | NBPC |
