| Onderdeel nommer | B156HW01 V0 |
| Handelsmerk | AUO |
| Grootte | 15.6 |
| Toepassing | NBPC |
| Resolusie | 1920×1080 |
| Samestelling | LCM |
| Helderheid | 300 |
| CR | 500:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| paneel handelsmerk | AUO |
| paneel model | B156HW01 V0 20 Compatible model |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 15.6 inch |
| resolusie | 1920(RGB)×1080 , FHD |
| vertoonmodus | TN, Normally White, Transmissive |
| aktiewe area | 344.16×193.59 mm |
| buitelyn | 359.3×209.5×5.7 mm |
| vorm styl | Wedge (PCBA Bent, Depth ≥5.2mm) |
| oppervlak | Glare (Haze 0%) |
| helderheid | 300 cd/m² (Typ.) |
| kontras verhouding | 500:1 (Typ.) |
| kleure vertoon | 262K (6-bit), CIE193160% |
| reaksie tyd | 2/6 (Typ.)(Tr/Td) |
| kykhoek | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | WLEDEmbedded (LED Driver) |
| sein koppelvlak | LVDS (2 ch, 6-bit), 40 pins |
| insetspanning | 3.3V (Typ.) |
| aansoek | NBPC |
| B156HAK01.0 | AUO | 15.6 | 1920×1080 |
| B156HTB01.0 | AUO | 15.6 | 1920×1080 |
| B156HTN01.1 | AUO | 15.6 | 1920×1080 |
| B156HTN03.3 | AUO | 15.6 | 1920×1080 |
| B156HTN04.0 | AUO | 15.6 | 1920×1080 |
| B156HW01 V0 | AUO | 15.6 | 1920×1080 |
| B156HW01 V1 | AUO | 15.6 | 1920×1080 |
| B156HW01 V3 | AUO | 15.6 | 1920×1080 |
| B156HW01 V7 | AUO | 15.6 | 1920×1080 |
| B156HW03 V0 | AUO | 15.6 | 1920×1080 |
| B121EW03 V6 | AUO | 12.1 | 1280×800 |
| B125XW02 V0 | AUO | 12.5 | 1366×768 |
| LP140WH1-TPD1 | LG Display | 14.0 | 1366×768 |
| LP150X08-TLAC | LG Display | 15.0 | 1024×768 |
| LP154WU1-A1K1 | LG Display | 15.4 | 1920×1200 |
| LTN121W3-L01 | Samsung | 12.1 | 1280×800 |
| LTN140KT13-B01 | Samsung | 14.0 | 1600×900 |
| LTN141AT16-B03 | Samsung | 14.1 | 1280×800 |
| LTN150PF-L03 | Samsung | 15.0 | 1400×1050 |
| N156O6-L01 | Innolux | 15.6 | 1600×900 |
