| Onderdeel nommer | CLAA080WQ05 XN |
| Handelsmerk | CPT |
| Grootte | 8.0 |
| Toepassing | Pad & Tablet Industr |
| Resolusie | 800×1280 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 800:1 |
| Kleure | 16.7M |
| Agterlig | 3S7P |
| Koppelvlak | |
| vervaardiger | CPT |
| skerm grootte | 8.0 inch |
| pixel nommer | 800(RGB)×1280 (WXGA) 188PPI |
| aktiewe area (mm) | 107.64 × 172.224 (H×V) |
| ring area (mm) | - |
| helderheid | 350 (Typ.)(cd/m²) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| goeie uitsig by | Symmetry |
| kleurdiepte | 16.7M 58% NTSC |
| massa | 115g (Max.) |
| herlaaitempo | 60Hz |
| model naam | CLAA080WQ05 XN |
| tipe skerm | LCM , a-Si TFT-LCD |
| reëling | RGB Vertical Stripe |
| buitelyn (mm) | 114.6 × 184.7 × 4.56 (H×V×D) |
| behandeling | Hard coating (3H) |
| kontras verhouding | 800 : 1 (Typ.) (TM) |
| werksmodus | HFFS, Normally Black, Transmissive |
| reaksie | 30 (Typ.)(Tr+Td) ms |
| agterlig | 3S7P WLED , 15K hours , No Driver |
| gebruik vir | Pad & Tablet Industrial |
| raakskerm | Without |
| CLAA080JA11CW | CPT | 8.0 | 480×220 |
| CLAA080LA0ACW | CPT | 8.0 | 800×480 |
| CLAA080LA0BCW | CPT | 8.0 | 800×480 |
| CLAA080LB0AXV | CPT | 8.0 | 800×480 |
| CLAA080LG01CW | CPT | 8.0 | 800×480 |
| CLAA080MB0DCW | CPT | 8.0 | 800×600 |
| CLAA080NA01 CW | CPT | 8.0 | 1024×600 |
| CLAA080UA01 | CPT | 8.0 | 1600×768 |
| CLAA080WQ02 XG | CPT | 8.0 | 800×1280 |
| CLAA080WQ08 XN | CPT | 8.0 | 800×1280 |
