| Onderdeel nommer | CLAA069LA0HCW |
| Handelsmerk | CPT |
| Grootte | 7.0 |
| Toepassing | Automotive Display |
| Resolusie | 800×480 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | |
| paneel handelsmerk | CPT |
| paneel grootte | 7.0" |
| resolusie | 800(RGB)×480, WVGA, 134PPI |
| vertoon area | 156.6(W)×81.6(H) mm |
| kykhoek | 75/75/60/70 (Typ.)(CR≥10) |
| beste uitsig op | 6 o'clock |
| kleure vertoon | 262K 70% NTSC |
| frekwensie | 60Hz |
| gewig | 165g (Typ.) |
| paneel model | CLAA069LA0HCW |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | - |
| vertoonmodus | TN, Normally White, Transmissive |
| reaksie tyd | 20 (Typ.)(Tr+Td) |
| tipe lamp | WLED |
| raakskerm | Without |
| aansoek | Automotive Display |
| CLAA061LA0ACW | CPT | 6.1 | 800×480 |
| CLAA061LA0BCW | CPT | 6.1 | 800×480 |
| CLAA069LA0ACW | CPT | 7.0 | 800×480 |
| CLAA069LA0FCW | CPT | 7.0 | 800×480 |
| CLAA069LA0NCW | CPT | 7.0 | 800×480 |
| CLAA069LA1AAW | CPT | 7.0 | 800×480 |
| CLAA069LB02CW | CPT | 7.0 | 800×480 |
| CLAA069LB03CW | CPT | 7.0 | 800×480 |
| CLAA069LB06 CW | CPT | 7.0 | 800×480 |
| CLAA069LC01XW | CPT | 7.0 | 800×480 |
