| Onderdeel nommer | BB055FHM-T00-6P01 |
| Handelsmerk | BOE |
| Grootte | 5.5 |
| Toepassing | Mobile Phone |
| Resolusie | 1080×1920 |
| Samestelling | AM-OLED , OLED |
| Helderheid | |
| CR | 17000:1 |
| Kleure | 16.7M |
| Agterlig | self |
| Koppelvlak | |
| paneel handelsmerk | BOE |
| paneel grootte | 5.5" |
| resolusie | 1080(RG/BG)×1920, FHD, 327PPI |
| vertoon area | 68.31(W)×121.44(H) mm |
| omtrek grootte | 70.71(W)×128.44(H) mm |
| helderheid | 350 cd/m² (Typ.) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| kleure vertoon | 16.7M 101% NTSC |
| frekwensie | 60Hz |
| gewig | TBD |
| paneel model | BB055FHM-T00-6P01 |
| paneel tipe | AM-OLED , OLED |
| pixel formaat | Sub-Pixel Rendering |
| ring opening | - |
| oppervlak | Hard coating |
| kontras verhouding | 17000:1 (Typ.) (TM) |
| vertoonmodus | - |
| reaksie tyd | - |
| tipe lamp | self |
| raakskerm | On-Cell Touch |
| aansoek | Mobile Phone |
| BT055FWM-N00 | BOE | 5.5 | 480×854 |
| E555HBM2 | EDO | 5.5 | 720×1280 |
| H546DAN01.2 | AUO | 5.5 | 1080×1920 |
| LM32C041 | SHARP | 5.5 | 320×240 |
| LM6Q35 | SHARP | 5.5 | 320×240 |
| LQ055T3SX02Z | SHARP | 5.5 | 1080×1920 |
| NL3224AC35-06 | NLT | 5.5 | 320×240 |
| NL3224AC35-10 | NLT | 5.5 | 320×240 |
| PW056XU1 | E Ink | 5.5 | 480×234 |
| UG-5664ASYGF01 | WiseChip | 5.5 | 256×64 |
