| Onderdeel nommer | B140QAN01.3 |
| Handelsmerk | AUO |
| Grootte | 14.0 |
| Toepassing | Laptop |
| Resolusie | 2560×1440 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 700:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | eDP |
| vervaardiger | AUO |
| skerm grootte | 14.0 inch |
| pixel nommer | 2560(RGB)×1440 (Quad-HD) 210PPI |
| aktiewe area (mm) | 309.35 × 174.01 (H×V) |
| helderheid | - |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| goeie uitsig by | Symmetry |
| kleurdiepte | 16.7M |
| omtrek vorm | Slim (PCBA Flat, T≤3.2mm) |
| herlaaitempo | 60Hz |
| sein tipe | eDP (4 Lanes) Connector |
| spanningstoevoer | 3.3V (Typ.) |
| maks. graderings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| model naam | B140QAN01.3 |
| tipe skerm | LCM , a-Si TFT-LCD |
| reëling | RGB Vertical Stripe |
| buitelyn (mm) | 320.4 × 198.6 × 2.6 (H×V×D) |
| kontras verhouding | 700 : 1 (Typ.) (TM) |
| reaksie | 25 (Typ.)(Tr+Td) ms |
| werksmodus | AHVA, Normally Black, Transmissive |
| agterlig | WLED , 15K hours , With LED Driver |
| gebruik vir | Laptop |
| raakskerm | Without |
| B140HAN01.0 | AUO | 14.0 | 1920×1080 |
| B140QAN01.0 | AUO | 14.0 | 2560×1440 |
| B140QAN01.1 | AUO | 14.0 | 2560×1440 |
| B140XW02 V1 | AUO | 14.0 | 1366×768 |
| HB140WX1-401 | BOE | 14.0 | 1366×768 |
| LP140WH1-TLA2 | LG Display | 14.0 | 1366×768 |
| LP140WH4-TLD1 | LG Display | 14.0 | 1366×768 |
| LTN140AT21-801 | Samsung | 14.0 | 1366×768 |
| N140HGE-EA1 | Innolux | 14.0 | 1920×1080 |
| NV140FHM-N41 | BOE | 14.0 | 1920×1080 |
