| Onderdeel nommer | B080EAK02.2 |
| Handelsmerk | AUO |
| Grootte | 8.0 |
| Toepassing | Pad & Tablet |
| Resolusie | 800×1280 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 900:1 |
| Kleure | 16.7M |
| Agterlig | 4S5P |
| Koppelvlak | MIPI |
| paneel handelsmerk | AUO |
| paneel model | B080EAK02.2 |
| paneel grootte | 8.0" |
| paneel tipe | a-Si TFT-LCD, LCM |
| resolusie | 800(RGB)×1280, WXGA, 188PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 107.64(W)×172.224(H) mm |
| ring opening | - |
| omtrek grootte | 113.72(W)×183.764(H) ×4.1(D) mm |
| oppervlak | Glare (Haze 0%) |
| helderheid | 360 cd/m² (Typ.) |
| kontras verhouding | 900:1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| vertoonmodus | AHVA, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 25 (Typ.)(Tr+Tf) |
| kleure vertoon | 16.7M 58% NTSC |
| tipe lamp | 4S5P WLED , 15K hours , Without Driver |
| frekwensie | 60Hz |
| raakskerm | Without |
| paneel gewig | 120g (Max.) |
| aansoek | Pad & Tablet |
| sein koppelvlak | MIPI (4 data lanes) , 39 pins Connector |
| insetspanning | 1.8/3.3V (Typ.)(VCC1/VC2) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| AT080TN03 V.1 | Innolux | 8.0 | 800×480 |
| AT080TN52 V.1 | Innolux | 8.0 | 800×600 |
| B080EAN01.1 | AUO | 8.0 | 800×1280 |
| B080EAN02.0 | AUO | 8.0 | 800×1280 |
| B080EAN02.2 | AUO | 8.0 | 800×1280 |
| C080VW04 V0 | AUO | 8.0 | 800×480 |
| CLAA080MB0DCW | CPT | 8.0 | 800×600 |
| LD080WX2-SMN1 | LG Display | 8.0 | 800×1280 |
| LT080EE04000 | TOSHIBA | 8.0 | 1600×768 |
| TM080TDHG01 | Tianma | 8.0 | 1024×768 |
